Monitor 5" wired

Monitor 5" wired

This monitor is used in combination with a maximum of 2 cameras. You can use this monitor as a replacement for any wired monitor in our range or new in combination with all wired cameras in our range.

Monitor specifications:

• Screen size: 5 ”(127mm) digital TFT panel monitor
• Screen resolution: 800RGB (H) x 480 (V) DOT
• Video mode: NTSC / PAL (auto switch)
• OSD menu: brightness; Contrast; Color; Mode; Language setting; Mirror; Directive; Reset
• Video: brightness: 300cd / m2 / contrast: 350: 1
• Cable connector: 9-pin connector (f) for camera (m)
• Cable length: 1.5 m
• Bracket Mount: U
• Voltage: 12-32 volts
• Dimensions: 146 x 110 x 26 mm
• Certification: EMC approved
